Description:

When you need a tractor for bigger and tougher jobs, look no further than the Yanmar YT359. Comfortable and easy to operate, the YT359 uses advanced electronic controls and an integrated hydraulic mechanical transmission (i-HMT). No longer do you have to choose between an efficient, constant speed and flexible operation. The i-HMT creates the standard for performance versatility.

• High power transfer ratio
• Repeatable operating speed
• Low fuel consumption due to increased transmission efficiency
• Step-less main shift
• Best speed possible for implement
• Clutch-less shifting
• Vehicle stop without clutch

Our YT3 Series tractors are designed to make work easier for people of all skill levels. The YT359 includes an autothrottle that enables you to control engine and travel speed with the accelerator/drive pedal. This makes operating the tractor like driving a car or truck with an automatic transmission car. A/B Mode lets you preset your maximum travel speed. An anti-stall feature keeps your engine running when you dig or lift a heavy load. There’s also cruise control to keep you moving efficiently when mowing or traveling for long stretches. YANMAR designs and builds the major components, engine, front axle, transmission, and final drive, to work together.

Features:

• Ergonomic operator station
• Controls on joystick
• Large LCD display integrates with controls
• Anti-stall
• Electronic cruise control
• Rear remote
• Loader control valve & joystick
• 12V outlet
• Advanced electronic controls
• Auto-throttle
• A/B Mode
• Throttle boost button
• i-HMT Transmission
• Loader 3rd function valve optional

Specifications:

 Powertrain

• Engine Model: Yanmar 4TNV98C (Tier 4)
• Gross Power: 58.9 HP (43.9 kW)
• PTO Power at working speed: 52.0 HP (38.3 kW)
• Rated RPM: 2,500
• Displacement: 202.5 cu. in. (3.318 L)
• Cylinders: 4, liquid-cooled, Common Rail Direct Injection
• Battery: 880 CCA
• Alternator: 12-55

Wheelbase: 77.4″ (1967 mm)

• Width: 70.6″ (1793 mm)
• Overall Length: 132.1″ (3355 mm)
• Height (ROPS): 95.7″ (2431 mm) / (CAB: 89.5″)
• Ground Clearance: 12.8″ (326 mm)
• Weight: 4,039 lbs (ROPS) / 4,442 lbs (CAB)

Capacities

• Fuel Tank: 12.7 gal (48 L)
• Cooling System: 7.8 qt (7.4 L)
• Engine Oil: 8.0 qt (7.6 L)
• Transmission Case: 7.7 gal (29 L)
• Front Axle: 2.4 gal (9 L)

Drivetrain & Hydraulics

• Transmission Type: i-HMT (3 ranges, variable speed)
• PTO: Rear 540 RPM
• 4WD Engagement: Selectable
• Brakes: Wet disc
• Hydraulic Pump (implement): 9.4 GPM (35.5 L/min)
• Hydraulic Pump (steering): 5.3 GPM (20.1 L/min)
• 3-Point Hitch: Cat. 1, lift capacity 3,307 lbs (1500 kgf)
• Power Steering: Fully hydraulic

YL610 Loader (Industrial Tires)

• Max Lift Height (pivot pin): 113″ (2870 mm)
• Dump Clearance: 88″ (2235 mm)
• Dump Reach @ Max Height: 15″ (376 mm)
• Max Dump Angle: 45°
• Bucket Rollback Angle: 40°
• Digging Depth (bucket level): 7.5″ (190 mm)
• Bucket Width: 72″ (1829 mm)
• Lift Capacity @ Pivot Pins: 2,500 lbs (1134 kg)
• Lift Capacity @ 500 mm forward: 1,795 lbs (814 kg)
• Breakout Force (pivot pins): 3,969 lbs (1800 kg)
• Raising Time (no load): 4.6 sec
• Lowering Time (no load): 3.1 sec
• Bucket Dump Time: 1.6 sec
• Rollback Time: 2.8 sec
• Rated Flow: 9.4 GPM (35.5 L/min)
• Relief Valve Pressure: 2,422 PSI (16.7 MPa)
• Bucket Capacity: 10.9 cu. ft. (0.309 m³)
• Bucket Weight: 319 lbs (145 kg)
• Loader Weight (no bucket): 776 lbs (352 kg)
